AIR802 DC to DC Coverter (10-26vdc to 48vdc) with PoE Output
You buy AIR802 DC to DC Coverter (10-26vdc to 48vdc) with PoE Output with Coupon : LOTET will be discounted 10%
.
Why Use AIR802 DC to DC Coverter (10-26vdc to 48vdc) with PoE Output ?
Design rich colors to choose fromOnline shopping for Automotive from a great selection of Tire & Wheel Tools, Diagnostic & Test Tools, Body Repair Tools, Garage . Find excellent deals on a variety of diagnostics tools and testing equipment . This pallet flag provides a twist on the usual flag design by replacing the blue field of stars with a cutout map of the United States with a string art star! Perfect for the 4th of July, this pallet flag will bring flea market style to your patriotic celebration!.AIR802 DC to DC Coverter (10-26vdc to 48vdc) with PoE Output will help your job easier dexThe model PDCPOE1248DR is a DC to DC converter with PoE Injector output. This product was designed for use in applications where 12 or 24 vdc (10 to 26 vdc) voltage input exists and the equipment being installed requires power-over-Ethernet (PoE) with 48 vdc.
There are two shielded Ethernet jacks on the top of the device. One jack is labeled, "Network" for network connecivity and will ordinarily connect to a switch, router, computer or other device. The other jack is labeled, "Equip + PoE" and is the output jack with 48vdc. Internally the data pins 1,2,3 and 6 are internally connected together between the two jacks.
Applications
Powering access points requiring 48vdc in autos, trucks. boats and RVs
Powering access points or other devices from 12 or 24 vdc solar systems
Oil & Gas Industry, Automotive, Marine, WISP and other sectors
Any scenario where 48vdc PoE is required from a 10 to 26 vdc supply
SPECIFICATIONS
Input DC Voltage Range: 10 to 26 vdc
Efficiency: 75 to 84% (typical)
Minimum Current: 3 amps @ 10 vdc
Input Options: PoE or Direct Screw Terminal
Output DC Voltage: 48 vdc
Maximum Current: 0.8 amps (0.6 amps typical)
Maximum Power: 36 watts
Voltage Tolerance: +/- 5%
Short Circuit Protection: Yes
Over Current Protection: Yes
Over Voltage Protection: Yes
Operating Temperature: -30ºC to 60ºC (-22º to 140ºF)
Storage Temperature: -30ºC to 70ºC (-22ºF to 158ºF)
Humidity: 5 to 90% RH
Safety Standards: UL 60950-1 (In process)
Mounting: DIN rail
Enclosure: Material PC UL 94 V-0
Dimensions - Height: 10cm (3.9 inches)
Dimensions - Depth: 9cm (3.5 inches) *from DIN rail mount to edge of DC connector
Dimensions - Width: 4cm (1.5 inches)
Weight: 224 grams (7.9 ounces)
You buy AIR802 DC to DC Coverter (10-26vdc to 48vdc) with PoE Output with Coupon : LOTET will be discounted 10%
